SRP7030-6R8M

BOURNS  SRP7030-6R8M  表面贴装功率电感器, SRP7030系列, 6.8 µH, ± 20%, 屏蔽, 0.05 ohm, 4.5 A

SRP7030 系列磁性屏蔽线绕扼流圈

屏蔽结构

装置高度 3.2mm

范围：0.1μH 至 10μH

电流高达 32.5A

符合 RoHs

应用于直流/直流转换器的输入/输出以及电源

立创商城:
6.8uH ±20% 4.5A 60mΩ

欧时:
Bourns SRP7030 系列 屏蔽 铁芯材 6.8 μH 绕线贴片电感器 SRP7030-6R8M, ±20%容差, 6A Idc

得捷:
FIXED IND 6.8UH 4.5A 60 MOHM SMD

贸泽:
Fixed Inductors 6.8uH 20% SMD 7030

e络盟:
功率电感SMD, 6.8 µH, 4.5 A, 屏蔽, 5.5 A, SRP7030系列, 7.6mm x 6.5mm x 3.2mm

艾睿:
This power SRP7030-6R8M surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 150 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 7.8 mm long, 3.2 mm tall and 7 mm deep. It has a tolerance of 20%. Its test frequency is 100K Hz. This device is made with wirewound technology. It has an inductance of 6.8u H. This SMD inductor has a maximum DC current of 4.5 A with a maximum resistance of 60m Ohm.

Allied Electronics:
SRP7030 Series Shielded WireWound SMD Inductor w/ Iron Core, 6.8 uH +/-20% 6A Idc

安富利:
Ind Power Shielded 6.8uH 20% 100KHz Iron 4.5A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 6.8uH 20% 100KHz Iron 4.5A 60mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 6.8uH 20% 100KHz Iron 4.5A 0.06Ohm DCR T/R

Newark:
# BOURNS  SRP7030-6R8M  Surface Mount Power Inductor, SRP7030 Series, 6.8 µH, 4.5 A, 5.5 A, Shielded, 0.05 ohm

MASTER:
Inductor Power - Shielded - Wirewound - 7.6 x 6.5 x 3.2mm - 6.8 uH - 100KHz - 4.5A - 60m Ohm.

Online Components:
Inductor Power Shielded Wirewound 6.8uH 20% 100KHz Iron 4.5A 60mOhm DCR T/R

Electro Sonic:
Inductor Power - Shielded - Wirewound - 7.6 x 6.5 x 3.2mm - 6.8 uH - 100KHz - 4.5A - ...
