SRR1206-180ML
数据手册.pdfBOURNS SRR1206-180ML 表面贴装功率电感器, SRR1206系列, 18 µH, ± 20%, 屏蔽, 0.05 ohm, 2.5 A
Inductor Power Shielded Wirewound 18uH 20% 1KHz 19Q-Factor Ferrite 2.5A 50mOhm DCR T/R
得捷:
FIXED IND 18UH 2.5A 50 MOHM SMD
e络盟:
功率电感SMD, 18 µH, 2.5 A, 屏蔽, 4.7 A, SRR1206系列, 12.7mm x 12.7mm x 6.5mm
艾睿:
This power SRR1206-180ML surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 14M Hz. This product is 13 mm long, 6.5 mm tall and 13 mm deep. This device utilizes wirewound technology. It has a tolerance of 20%. It has an inductance of 18u H. This SMD inductor has a maximum DC current of 2.5 A with a maximum resistance of 50m Ohm.
安富利:
Ind Power Shielded Wirewound 18uH 20% 1KHz 19Q-Factor Ferrite 2.5A T/R
Verical:
Inductor Power Shielded Wirewound 18uH 20% 1KHz 19Q-Factor Ferrite 2.5A 0.05Ohm DCR T/R
Newark:
# BOURNS SRR1206-180ML Surface Mount Power Inductor, SRR1206 Series, 18 H, 20%, Shielded, 0.05 ohm, 2.5 A
Online Components:
Inductor Power Shielded Wirewound 18uH 20% 1KHz 19Q-Factor Ferrite 2.5A 50mOhm DCR T/R
Electro Sonic:
Inductor Power Shielded Wirewound 18uH 20% 1KHz 19Q-Factor Ferrite 2.5A 50mOhm DCR T/R
