SRR1005-270Y

屏蔽式功率电感器 Shielded Power Inductors

Features

■ Available in E12 series

■ Unit height of 5.2mm

■ Current up to 4.5A

Applications

■ Input/output of DC/DC converters

■ Power supplies for:

  • Portable communication equipment

  • Camcorders

  • LCD TVs

  • Car radios

得捷:
FIXED IND 27UH 1.3A 120 MOHM SMD

贸泽:
Fixed Inductors 27uH 30% SMD 1005

艾睿:
This power SRR1005-270Y surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This device utilizes wirewound technology. It has a tolerance of 15%. It has an inductance of 27u H. This product is 12.8 mm long, 5.2 mm tall and 10.2 mm deep. This SMD inductor has a maximum DC current of 1.3 A with a maximum resistance of 120m Ohm. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 17M Hz.

安富利:
Ind Power Shielded Wirewound 27uH 15% 1KHz 40Q-Factor Ferrite 1.3A T/R

Verical:
Inductor Power Shielded Wirewound 27uH 15% 1KHz 40Q-Factor Ferrite 1.3A 0.12Ohm DCR T/R
