SDR1307-221KL

BOURNS  SDR1307-221KL  表面贴装功率电感器, SDR1307系列, 220 µH, ± 10%, 非屏蔽, 0.36 ohm, 1.3 A

220 µH 无屏蔽 绕线 器 1.3 A 360 毫欧最大 非标准

得捷:
FIXED IND 220UH 1.3A 360MOHM SMD

立创商城:
220uH ±10% 1.3A 360mΩ

e络盟:
功率电感SMD, 220 µH, 1.3 A, 非屏蔽, 2.1 A, SDR1307系列, 13mm x 13mm x 7mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SDR1307-221KL surface mount inductor from Bourns to save valuable space. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has an inductance of 220u H. This SMD inductor has a maximum DC current of 1.3 A with a maximum resistance of 360m Ohm. This device utilizes wirewound technology. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 3.8M Hz. It has a tolerance of 10%. This product is 7.3 mm tall with a diameter of 13.5 mm.

安富利:
Ind Power Wirewound 220uH 10% 100KHz 15Q-Factor Ferrite 1.3A T/R

Verical:
Inductor Power Unshielded Wirewound 220uH 10% 100KHz 15Q-Factor Ferrite 1.3A 0.36Ohm DCR T/R

Newark:
# BOURNS  SDR1307-221KL  Surface Mount Power Inductor, SDR1307 Series, 220 H, 10%, Unshielded, 0.36 ohm, 1.3 A

MASTER:
Inductor Power Wirewound 220uH 10% 100KHz 15Q-Factor Ferrite 1.3A 360mOhm DCR T/R

Online Components:
Inductor Power Wirewound 220uH 10% 100KHz 15Q-Factor Ferrite 1.3A 360mOhm DCR T/R

Electro Sonic:
Inductor Power Wirewound 220uH 10% 100KHz 15Q-Factor Ferrite 1.3A 360mOhm DCR T/R
