SRU1028-4R7Y

SHIELDED SMD功率电感 Shielded SMD Power Inductors

**Features

**

* Unit Height of 2.8 mm**

**

* Current Up to 7 A**

**

* Lead-Free**

Applications

**

* Input/Output of DC/DC Converters**

**

* Power Supplies For:**

**Portable Communication Equipment**

**Camcorders**

**LCD TVs**

**Car Radios

得捷:
FIXED IND 4.7UH 4.5A 16 MOHM SMD

立创商城:
4.7uH ±30% 4.5A 16mΩ

贸泽:
Fixed Inductors 4.7uH 30% SMD 1028

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SRU1028-4R7Y surface mount inductor from Bourns to save valuable space. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This device is made with wirewound technology. It has an inductance of 4.7u H. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 40M Hz. This SMD inductor has a maximum DC current of 4.5 A with a maximum resistance of 16m Ohm. This product is 10.3 mm long, 3.1 mm tall and 10.3 mm deep.

Allied Electronics:
Inductor, SMT Power/Shielded; 4.7uH; 30% Tol; SRF Min 40MHz; DCR 0.017 Ohm; 12 Qref

安富利:
Ind Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A 16mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A 0.016Ohm DCR T/R

Newark:
# BOURNS  SRU1028-4R7Y  Surface Mount Power Inductor, SRU1028 Series, 4.7 µH, 4.5 A, 3.8 A, Shielded, 0.016 ohm

MASTER:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A 16mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A 16mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 12Q-Factor Ferrite 4.5A 16mOhm DCR T/R

Win Source:
FIXED IND 4.7UH 4.5A 16 MOHM SMD / 4.7 µH Shielded Drum Core, Wirewound Inductor 4.5 A 16mOhm Nonstandard
