SMAJ170A

SMAJ系列 275V 0.4kW 表面贴装 单向 瞬态电压抑制二极管 DO-214AC

275V Clamp 1.5A Ipp Tvs Diode Surface Mount DO-214AC SMA

得捷:
TVS DIODE 170VWM 275VC DO214AC

立创商城:
单向 Vrwm:170V

贸泽:
ESD Suppressors / TVS Diodes 170Vr 400W 1.5A 5% UniDirectional

艾睿:
Surges can be a costly problem, avoid the pain and suffering by implementing this SMAJ170A TVS diode from Littelfuse. Its test current is 1 mA. Its peak pulse power dissipation is 400 W. This device&s;s maximum clamping voltage is 275 V and minimum breakdown voltage is 189 V. Its maximum leakage current is 1 μA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.

Chip1Stop:
Diode TVS Single Uni-Dir 170V 400W 2-Pin DO-214-AC T/R

TME:
Diode: transil; 400W; 199V; 1.5A; unidirectional; ±5%; DO214AC

Verical:
Diode TVS Single Uni-Dir 170V 400W 2-Pin SMAJ T/R

Newark:
# LITTELFUSE  SMAJ170A  TVS Diode, Unidirectional, 170 V, 275 V, DO-214AC, 2 Pins

儒卓力:
**TVS-DIODE UNI 0,4KW 199V SMA **

Win Source:
TVS DIODE 170VWM 275VC SMA
