SMAJ58

Trans Voltage Suppressor Diode, 400W, 58V VRWM, Unidirectional, 1Element, Silicon, DO-214AC, HALOGEN FREE AND ROHS COMPLIANT, PLASTIC, SMA, 2Pin

98.28V 夹子 4.3A Ipp TVS - 表面贴装型 DO-214AC（SMA）

得捷:
TVS DIODE 58VWM 98.28VC DO214AC

贸泽:
ESD Suppressors / TVS Diodes 58Vr 400W 4.3A 10% UniDirectional

艾睿:
Littelfuse&s;s SMAJ58 TVS diode is designed to protect electronic components and circuits from electrical overstress from overvoltage and electrostatic discharge. Its test current is 1 mA. Its maximum leakage current is 1 μA. This device&s;s maximum clamping voltage is 93.6 V and minimum breakdown voltage is 61.02 V. Its peak pulse power dissipation is 400 W. This TVS diode has an operating temperature range of -55 °C to 150 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery.

Chip1Stop:
Diode TVS Single Uni-Dir 58V 400W 2-Pin SMA T/R
