STM32L052K8T6
数据手册.pdfSTMICROELECTRONICS STM32L052K8T6 微控制器, 32位, 超低功率, ARM 皮质-M0+, 32 MHz, 64 KB, 8 KB, 32 引脚, LQFP
The is a Microcontroller Unit incorporates the connectivity power of the universal serial bus with the high-performance ARM® Cortex®-M0+ 32-bit RISC core operating at a 32MHz frequency, a memory protection unit MPU, high-speed embedded memories plus an extensive range of enhanced I/Os and peripherals. This device provides high power efficiency for a wide range of performance. It is achieved with a large choice of internal and external clock sources, an internal voltage adaptation and several low-power modes.
- .
- Ultralow-power platform
- .
- 1.65 to 3.6V Power supply
- .
- 0.27µA Standby mode 2 wakeup pins
- .
- 88µA/MHz Run mode
- .
- From 32kHz up to 32MHz maximum
- .
- Ultra-safe, low-power BOR with 5
- .
- Ultralow power POR/PDR
- .
- Programmable voltage detector PVD
- .
- 1 to 25MHz Crystal oscillator
- .
- 32kHz Oscillator for RTC with calibration
- .
- Programmable voltage detector PVD
- .
- Serial wire debug supported
- .
- Rich analogue peripherals
- .
- 12-bit ADC 1.14Msps Up to 16 channels down to 1.65V
- .
- 2x Ultralow-power comparators
- .
- Up to 24 capacitive sensing channels supporting touchkey, linear and rotary touch sensors
- .
- 8x Peripheral communication interfaces
- .
- CRC calculation unit
- .
- 96-bit Unique ID
- .
- True RNG and firewall protection
