SRP1238A-4R7M

BOURNS  SRP1238A-4R7M  表面贴装功率电感器, AEC-Q200 SRP1238A系列, 4.7 µH, ± 20%, 屏蔽, 0.0185 ohm, 10 A

SRP1238A 系列磁性屏蔽式功率器

Bourns SRP 系列高电流电感器具有羰基粉芯且符合 AEC-Q200。

**特点和优势：**

SRP1238A 系列电感器具有屏蔽结构

羰基粉芯

高饱和电流

电感范围 0.10 μH 至 10 μH

符合 AEC-Q200

符合 RoHS 标准且无卤

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流-直流转换器和电源

立创商城:
4.7uH ±20% 10A 15.3mΩ

得捷:
FIXED IND 4.7UH 10A 18.5MOHM SMD

欧时:
Bourns SRP1238A 系列 屏蔽 羰基粉芯材 4.7 μH 绕线贴片电感器 SRP1238A-4R7M, ±20%容差, 10A Idc

贸泽:
Fixed Inductors 4.7uH 20% SMD 1238 AEC-Q200

e络盟:
功率电感SMD, 4.7 µH, 10 A, 屏蔽, 24 A, SRP1238A 系列, 13.5mm x 12.5mm x 3.3mm

艾睿:
Use this power SRP1238A-4R7M surface mount inductor from Bourns to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 150 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 20%. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 15MTyp Hz. This SMD inductor has a maximum DC current of 10 A with a maximum resistance of 18.5m Ohm. This product is 14 mm long, 3.5 mm tall and 12.8 mm deep. This device is made with wirewound technology. It has an inductance of 4.7u H.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 4.7uH 20% SMT 1238

安富利:
Ind Power Shielded 4.7uH 20% 100KHz Carbonyl Powder 10A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 4.7uH 20% 100KHz 20Q-Factor Carbonyl Powder 10A 18.5mOhm DCR Automotive T/R

Verical:
Inductor Power Shielded Wirewound 4.7uH 20% 100KHz 20Q-Factor Carbonyl Powder 10A 0.0185Ohm DCR Automotive T/R

Newark:
# BOURNS  SRP1238A-4R7M  Surface Mount Power Inductor, AEC-Q200 SRP1238A Series, 4.7 H, 20%, Shielded, 0.0185 ohm, 10 A
