RC0805FR-074R7L
数据手册.pdf0805 格式 RC0805 系列卷装（0Ω 至 910Ω）适用于拾放机 以卷为单位（5000 件）出售 70°C 时功率 | 0.125 W ---|--- 温度系数 | ±100ppm/°C 工作温度 | -55°C 至 +155°C 最大工作电压 | 150V 尺寸（长x宽x厚） | 2.00 x 1.25 x 0.50 mm 跳线芯片电阻 | 0.05Ω 跳线芯片电流 | 2A（最大 5A） ### 厚膜 - 0805### 应用包括：电信设备 收音机和录音机，TV 调谐器 摄像机，表，袖珍计算器 汽车工业 计算机，仪器
SMD器/芯片电阻器
得捷:
RES 4.7 OHM 1% 1/8W 0805
欧时:
Yageo RC0805 系列 0.125W 4.7Ω 厚膜SMD 电阻器 RC0805FR-074R7L, ±1%, ±200ppm/°C, 0805 封装
立创商城:
4.7Ω ±1% 125mW
贸泽:
Thick Film Resistors - SMD 4.7 OHM 1%
e络盟:
SMD片式电阻, 厚膜, 0805 [2012公制], 4.7 ohm, RC系列, 150 V, 厚膜, 125 mW
艾睿:
Use this RC0805FR-074R7L fixed single surface-mount resistor from Yageo to obtain a visually clean layout. This dependable part has a power rating of 0.125 1/8 W. This product has a resistance value of 4.7 Ohm. Its temperature coefficient is ±200 ppm/°C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a tolerance of 1%. This product is 2 mm long, 0.5 mm tall and 1.25 mm deep. This part has an operating temperature of -55 to 155 °C. This device utilizes thick film technology.
Chip1Stop:
Res Thick Film 0805 4.7 Ohm 1% 1/8W ±200ppm/℃ Molded SMD Paper T/R
Verical:
Res Thick Film 0805 4.7 Ohm 1% 0.125W1/8W ±200ppm/C Epoxy Pad SMD T/R
Newark:
# YAGEO PHYCOMP RC0805FR-074R7L Surface Mount Thick Film Resistor, RC Series, 4.7 ohm, 125 mW, - 1%, 150 V, 0805 [2012 Metric]
儒卓力:
**RC0805 4,7R 1% 0,125W TK200 **
