PIC24FV16KM202-I/SO

MICROCHIP  PIC24FV16KM202-I/SO.  芯片, 微控制器, 16位, PIC24FV, 16MIPS, SOIC-28

The is a high-performance PIC24F family eXtreme low power technology 16-bit Microcontroller packs powerful PIC®RISC architecture with up to 16 MIPS of performance at 3.3V with Basic code-guard security. This product offer all of the advantages of the well recognized high-performance x16 architecture with standardized features including 16kB of addressable program memory size, 2048bytes of data memory size, 24 general-purpose I/O pins, 19-channel 10/12-bit analog-to-digital A/D converter and two 8-bit digital-to-analog D/A converter. This device operates at a maximum frequency of 32MHz with wide operating voltage of 2 to 5.5V.

.

XLP Technology for Sleep current at low as 20nA

.

Brown-out reset BOR

.

Low voltage detection LVD

.

Power on reset POR

.

Watch dog timer WDT

.

nanoWatt XLP technology

.

Three comparators

.

Internal voltage reference

.

2x Operational amplifier

.

Charge time measurement unit CTMU

.

2x Configurable logic cells

.

Local interconnect network LIN

.

IrDA

.

2x Single-output capture compare PWM module SCCP

.

3x Multiple-output capture compare PWM module MCCP

.

Parallel port GPIO

.

Eleven 16-bit timers

.

Five 32-bit timers

.

Programmable Cyclic Redundancy Check CRC

.

512bytes of EEPROM data memory
