P0915N-FC15BR10K
数据手册.pdf电位计 9 mm ROTARY PANEL POT
10k 欧姆 1 组 线性 面板安装 电位计 无 1 匝 导电塑料 0.05W，1/20W PC 引脚，板锁
得捷:
POT 10K OHM 1/20W PLASTIC LINEAR
贸泽:
电位计 9 mm ROTARY PANEL POT
艾睿:
This P0915N-FC15BR10K potentiometer from BI Technologies TT electronics is designed to optimize functionality and calibrate the resistance in your circuit. This product has a resistance value of 10K Ohm. This part has a power rating of 0.05 1/20 W. This device utilizes conductive plastic technology. It has a tolerance of 20%. This part has an operating temperature of -10 to 70 °C. The P0915N-FC15BR10K part has a pin termination style. This product is 12.1 mm long, 28.5 mm tall and 14.85 mm deep.
Chip1Stop:
Res Conductive Plastic POT 10K Ohm 20% 0.05W1/20W 1Elec/1MechTurns 6mm 12.1 X 14.85 X 28.5mm Pin Panel Mount/Through Hole
Verical:
Res Conductive Plastic POT 10K Ohm 20% 0.05W1/20W 1Elec/1MechTurns 6mm 12.1 X 14.85 X 28.5mm Pin Panel Mount/Through Hole Box/Tray
MASTER:
Potentiometer - Single Gang - 10K +/- 20% - 0.05W - Linear Taper - Top Adjust - D Shaped Shaft 15mm Long - PCB Through Hole
Online Components:
Res Conductive Plastic POT 10K Ohm 20% 0.05W1/20W 1Elec/1MechTurns 6mm 12.1 X 14.85 X 28.5mm Pin Panel Mount/Through Hole
Electro Sonic:
Potentiometer - Single Gang - 10K +/- 20% - 0.05W - Linear Taper - Top Adjust - D Shaped Shaft ...
