PM127SH-4R7N-RC
数据手册.pdfBOURNS JW MILLER PM127SH-4R7N-RC 表面贴装功率电感器, PM127SH系列, 4.7 µH, -20%至+40%, 屏蔽, 0.0155 ohm, 8.2 A
The PM127SH series SMD shielded Power Inductor with ferrite DR and RI core. It has tin/nickel/copper termination and an enamelled copper wire winding. It is suitable for input/output of DC/DC converters.
- .
- Formerly JW Miller® model
- .
- -40 to 125°C Operating temperature range
得捷:
FIXED IND 4.7UH 8.2A 15.5MOHM SM
立创商城:
4.7uH -20%~+40% 8.2A 15.5mΩ
e络盟:
BOURNS JW MILLER PM127SH-4R7N-RC 表面贴装功率电感器, PM127SH系列, 4.7 µH, -20%至+40%, 屏蔽, 0.0155 ohm, 8.2 A
艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power PM127SH-4R7N-RC surface mount inductor from Bourns to save valuable space. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 12.8 mm long, 8 mm tall and 12.8 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 30MTyp Hz. This device utilizes bobbin core technology. This SMD inductor has a maximum DC current of 8.2 A with a maximum resistance of 15.5m Ohm. It has an inductance of 4.7u H.
安富利:
Ind Power Shielded Bobbin Core 4.7uH -20% to 40% 100KHz 22Q-Factor Ferrite 8.2A T/R
Verical:
Inductor Power Shielded Bobbin Core 4.7uH -20% to 40% 100KHz 22Q-Factor Ferrite 8.2A 0.0155Ohm DCR T/R
Newark:
# BOURNS JW MILLER PM127SH-4R7N-RC Surface Mount Power Inductor, PM127SH Series, 4.7 µH, 8.2 A, 8.8 A, Shielded, 0.0155 ohm
Electro Sonic:
Inductor Power Shielded Bobbin Core 4.7uH -20% to 40% 100KHz 22Q-Factor Ferrite 8.2A 15.5mOhm DCR T/R
