PM3316-471M-RC

BOURNS JW MILLER  PM3316-471M-RC  功率电感, 470uH, 20%容差, SMD

**Features:

**

* Formerly J.W. Miller Model

* Low Profile of Only 5.0 mm

* Inductance as Low as 1.0 μH**

Applications:

**

* Input/Output of DC/DC Converters

* Power Supplies for: Portable Communication Equipment, Camcorders, LCD TVs and Car Radios

立创商城:
470uH ±20% 450mA 1.7Ω

得捷:
FIXED IND 470UH 450MA 1.7OHM SMD

贸泽:
Fixed Inductors 470uH 20%

e络盟:
功率电感, 470uH, 20%容差, SMD

艾睿:
This power PM3316-471M-RC surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device is made with wirewound technology. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 4M Hz. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 450m A with a maximum resistance of 1.7 Ohm. This product is 12.9 mm long, 5.3 mm tall and 10.2 mm deep. It has an inductance of 470u H.

Allied Electronics:
Inductor; SMT Pwr; 470uH; 20%; 1.70 DCR

安富利:
Ind Power Wirewound 470uH 20% 1KHz 57Q-Factor Ferrite 450mA T/R

Chip1Stop:
Ind Power Wirewound 470uH 20% 1KHz 57Q-Factor Ferrite 450mA T/R

Verical:
Inductor Power Wirewound 470uH 20% 1KHz 57Q-Factor Ferrite 0.45A 1.7Ohm DCR T/R

Newark:
# BOURNS JW MILLER  PM3316-471M-RC  Surface Mount Power Inductor, PM3316 Series, 470 µH, 450 mA, 500 mA, Unshielded, 1.7 ohm

MASTER:
Inductor Power Wirewound 470uH 20% 1KHz 57Q-Factor Ferrite 450mA 1.7Ohm DCR T/R

Electro Sonic:
Inductor Power Wirewound 470uH 20% 1KHz 57Q-Factor Ferrite 450mA 1.7Ohm DCR T/R
