P4SMA82CA
数据手册.pdfLittelfuse(力特)
分立器件
硅雪崩二极管 - 400W表面贴装瞬态电压抑制器 Silicon Avalanche Diodes - 400W Surface Mount Transient Voltage Supressors
400W Surface Mount Transient Voltage Supressors
FEATURES
•RoHScompliant
•For surface mounted applications in order to optimize board space
•Low profile package
•Built-in strain relief
•Glass passivated junction
•Low Inductance
•Excellent clamping capability
•Repetition Rate duty cycle:0.01%
•Fast response time: typically less than 1.0ps from 0 Volts to VBR for unidirectional types
•Typical IR less than 1µA above 10V
•High temperature soldering: 250˚C/10 seconds at terminals
DEVICES FOR BIPOLAR APPLICATION
For Bidirectional use Suffix CA for types P4SMA6.8CA thru types P4SMA550CA
Electrical characteristics apply in both directions
