PIC16LF1719-I/MV

PIC 32MHz 闪存：16K@x14bit

* Core Features: * C Compiler Optimized RISC Architecture * Only 49 Instructions * Operating Speed: * 0-32 MHz clock input * 125 ns minimum instruction cycle * Interrupt Capability * 16-Level Deep Hardware Stack * Up to Four 8-Bit Timers * One 16-Bit Timer * Power-on Reset POR * Power-up Timer PWRT * Low-Power Brown-Out Reset LPBOR * Programmable Watchdog Timer WDT up to 256s * Programmable Code Protection * Memory: * Up to 16 Kwords Flash Program Memory * Up to 2048 Bytes Data SRAM Memory * Direct, Indirect and Relative Addressing modes * Operating Characteristics: * Operating Voltage Range: * 1.8V to 3.6V PIC16LF1717/8/9 * 2.3V to 5.5V PIC16F1717/8/9 * Temperature Range: * Industrial: -40°C to 85°C * Extended: -40°C to 125°C * eXtreme Low-Power XLP Features: * Sleep mode: 50 nA @ 1.8V, typical * Watchdog Timer: 500 nA @ 1.8V, typical * Secondary Oscillator: 500 nA @ 32 kHz * Operating Current: * 8 µA @ 32 kHz, 1.8V, typical * 32 µA/MHz @ 1.8V, typical * Digital Peripherals: * Configurable Logic Cell CLC: * Integrated combinational and sequential logic * Complementary Output Generator COG: * Rising/falling edge dead-band control/ blanking * Numerically Controlled Oscillator NCO: * Generates true linear frequency control and increased frequency resolution * Input Clock: 0 Hz < FNCO < 32 MHz * Resolution: FNCO/220 * Capture/Compare/PWM CCP module * PWM: Two 10-Bit Pulse-Width Modulators * Serial Communications: * SPI, I2C™, RS-232, RS-485, LIN compatible * Auto-Baud Detect, auto-wake-up on start * Up to 35 I/O Pins and One Input Pin: * Individually programmable pull-ups * Slew rate control * Interrupt-on-change with edge-select * Peripheral Pin Select PPS: * Enables pin mapping of digital I/O * Intelligent Analog Peripherals: * Operational Amplifiers: * Two configurable rail-to-rail op amps * Selectable internal and external channels * 2 MHz gain bandwidth product * High-Speed Comparators: * Up to two comparators * 50 ns response time * Rail-to-rail inputs * 10-Bit Analog-to-Digital Converter ADC: * Up to 28 external channels * Conversion available during Sleep * Temperature indicator * Zero-Cross Detector ZCD: * Detect when AC signal on pin crosses ground * 8-Bit Digital-to-Analog Converter DAC.
