MPLAD15KP33CA

33V 15000W

These high power 15 kW rated transient voltage suppressors in a surface mount package are provided with design features to minimize thermal resistance and cumulative heating. They are particularly effective at meeting the multi-stroke lightning standard RTCA DO-160, section 22 for aircraft design. This efficient low profile package design is offered in standoff voltage selections Vwm of 7 volt to 200 volts in either unidirectional or bidirectional construction.

立创商城:
Vrwm:33V 15kW

艾睿:
Do not risk expensive equipment and machinery from surges with this MPLAD15KP33CA TVS diode from Microsemi. Its peak pulse power dissipation is 15000 W. Its test current is 5 mA. This device&s;s maximum clamping voltage is 53.3 V and minimum breakdown voltage is 36.7 V. Its maximum leakage current is 10 μA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C.
