MX7534JCWP

微处理器兼容， 14位DAC Microprocessor-Compatible, 14-Bit DACs

General Description

The MX7534/MX7535 are high-performance, CMOS, monolithic, 14-bit digital-to-analog converters DACs. Wafer-level, laser-trimmed, thin-film resistors and temperature-compensated NMOS switches assure operation over the full operating temperature range with exceptional linear and gain stability.

Features

♦ 14-Bit Monotonic Over Full Temperature Range

♦ Full 4-Quadrant Multiplication

♦ µP-Compatible, Double-Buffered Inputs

♦ Exceptionally Low Gain Tempco 2.5ppm/°C

♦ Low Output Leakage <20nA Over Temp.

♦ Low Power Consumption

♦ TTL and CMOS Compatible

Applications

  Machine and Motion Control Systems

  Automatic Test Equipment

  Digital Audio

  µP-Controlled Calibration Circuitry

  Programmable-Gain Amplifiers

  Digitally Controlled Filters

  Programmable Power Supplies
