MWDM2L-51PCBRP-.110
数据手册.pdf
Glenair
连接器
连接器, 微型D sub, 51 触点, 插头, MWDM-CBR Series, 焊接, 面板安装, 通孔安装直角, 镀金触芯
The from is a Micro-D MWDM-BR right angle through hole PCB connector with 51 contacts. Terminals are coated with Sn60/Pb40 tin-lead solder for best solderability.
- .
- Aluminium alloy shell with nickel plating
- .
- Liquid crystal polymer LCP/ polyphenylene sulphidePPS insulator
- .
- Copper alloy pin contacts gold over nickel plating
- .
- Blue colour fluorosilicone rubber interfacial seal
- .
- Current rating is 3A, DWV is 600VAC sea level
- .
- Minimum insulation resistance is 5000Mohm, maximum contact resistance is 8mohm
- .
- Operating temperature range from -55°C to +150°C
- .
- Solder dipped gold plated copper alloy PCB terminals
- .
- Terminal length is 0.110inch
- .
- Standard jackpost
