M83513/13-B01NP

Glenair Micro D PCB Connectors MIL-DTL-83513, Narrow Profile, Right AngleGlenair Micro D narrow profile right angle military grade printed circuit board connectors are a robust and durable board mount connector, featuring an electroless nickel plated metal shell, these connectors are potted with epoxy resin and are environmentally sealed. The connector contact terminals are spaced on .100 inch by .100 inch centers.Electroless nickel plated metal shell Attached jackposts Printed circuit tail length .109 Inches Current rating 3A max. Magnetic permeability 2.0 μΩ max Operating temp -55 to +150 °C 500 mating cycles ### 注Pin connector shown.### 标准MIL-DTL-83513, BS9523F0002

Micro D PCB Connectors MIL-DTL-83513, Narrow Profile, Right Angle

Glenair Micro D narrow profile right angle military grade printed circuit board connectors are a robust and durable board mount connector, featuring an electroless nickel plated metal shell, these connectors are potted with epoxy resin and are environmentally sealed. The connector contact terminals are spaced on .100 inch by .100 inch centers.

Electroless nickel plated metal shell

Attached jackposts

Printed circuit tail length .109 Inches

Current rating 3A max.

Magnetic permeability 2.0 μΩ max

Operating temp -55 to +150 °C

500 mating cycles

### 注

Pin connector shown.

### 标准

MIL-DTL-83513, BS9523F0002
