MAX5214GUA+T
数据手册.pdfMaxim Integrated(美信)
主动器件
DAC 1CH Segment 14Bit 8Pin uMAX T/R
* Low-Power Consumption 80µA max * 14-/16-Bit Resolution in a 3mm x 5mm, 8-Pin µMAX Package * Relative Accuracy * ±0.40 LSB INL MAX5214, 14-Bit typ, ±1 LSB max * ±1.2 LSB INL MAX5216, 16-Bit typ, ±4 LSB max * Guaranteed Monotonic Over All Operating Ranges * Low Gain and Offset Error * Wide 2.7V to 5.5V Supply Range * Rail-to-Rail Buffered Output Operation * Safe Power-On Reset POR to Zero DAC Output * Fast 50MHz, 3-Wire, SPI/QSPI/MICROWIRE-Compatible Serial Interface * Schmitt-Trigger Inputs for Direct Optocoupler Interface * Asynchronous Active-Low CLR Clears DAC Output to Code 0 * High Reference Input Resistance for Power Reduction * Buffered Voltage Output Directly Drives 10kΩ Loads
