MAX13234EETP+

MAXIM INTEGRATED PRODUCTS  MAX13234EETP+  芯片, RS232 收发器, 250KBPS, 5.5V, TQFN-20

The is a ±15KV ESD protected, 250Kbps RS232 transceiver with low voltage interface in 20 pin TQFN package. This 2x2 RS232 and V.28/V.24 transceiver with data rate of 250Kbps operates from either a 3.3V or 5V supply. It has an AutoShutdown Plus feature that achieves 1µA shutdown current and reduces power consumption. The device automatically enters a low power shutdown mode when the RS232 cable is disconnected or the device driving the transmitter and receiver inputs are inactive for more than 30 seconds.

.

Supply voltage range is 3V to 5.5V

.

Operating temperature range from -40°C to 85°C

.

Integrated low voltage logic for easy interface with ASICs and microcontrollers

.

Integrated ±15KV HBM ESD protection

.

Integrated charge pump circuitry requiring only four external 0.1µF capacitors for 3.3V operation
