MAX313LCSE+T
数据手册.pdfSPST, 4 Func, 1Channel, CMOS, PDSO16, 0.15INCH, ROHS COMPLIANT, SOIC-16
4 电路 IC 开关 1：1 10 欧姆 16-SOIC
立创商城:
MAX313LCSE+T
得捷:
IC SWITCH QUAD SPST 16SOIC
安富利:
Maxim"s MAX312L/MAX313L/MAX314L analog switches feature low on-resistance 10Ω max and 1.5Ω on-resistance matching between channels. These switches are +3V logic compatible when powered from ±15V or +12V supplies. The switches conduct equally well in either direction, and offer low leakage over temperature 2.5nA at +85°C.The MAX312L/MAX313L/MAX314L are quad, single-pole/single-throw SPST analog switches. The MAX312L is normally closed NC, and the MAX313L is normally open NO. The MAX314L has two NC switches and two NO switches. All three devices operate from a single +4.5V to +36V supply or from dual ±4.5V to ±20V, and are available in 16-pin TSSOP, SO, and DIP packages.
