MAX4899AEETE+T

MAXIM INTEGRATED PRODUCTS  MAX4899AEETE+T  芯片, 模拟多路复用器, 双路, 4:1, TQFN-16

The is a USB 2.0 high speed, fault-tolerant, 4:1 multiplexer in 16 pin TQFN package. This analogue multiplexer combines low on-capacitance CON and low on-resistance RON necessary for high performance switching applications. The device is designed for USB 2.0 high speed applications at 480Mbps and also handle all requirements for USB low and full-speed signalling. It features two digital inputs, C0 and C1, to control analogue signal path. Typical applications include switching a USB connector between USB and other operations such as serial communications, audio and video. An enable input EN - complementary is provided to disable all channels and place device into a high impedance off state as well as reducing power consumption. It operates from a 2.7V to 3.6V power supply voltage and protected against +5.5V shorts to COMA- and COMA+. In addition, COMA+ and COMA- are normally connected to outside circuitry and feature ±15kV ESD protection.

.

Low 4ohm typ on-resistance RON

.

Operating temperature range from -40°C to 85°C

.

425MHz -3dB bandwidth

.

Fault tolerant to meet full USB 2.0 specification

.

Low operating current 200µA, ultra low quiescent current of 3.0µA max in standby mode

.

Low threshold eliminates need for translators in 1.8V low voltage systems

.

Crosstalk of -50dB at f = 50MHz
