MAX395CWG+

MAXIM INTEGRATED PRODUCTS  MAX395CWG+  模拟开关, 低电压, SPST, 8 放大器, 100 ohm, 2.7V至16V, ± 2.7V至± 8V, WSOIC, 24 引脚

The is a serially controlled, low voltage, 8-channel SPST switch in 24 pin WSOIC package. This CMOS device can operate continuously with dual power supplies and off leakage current is only 0.1nA at +25°C or 5nA at +85°C. Upon power-up, all switches are off and the internal shift registers are reset to zero. Device is electrically equivalent to two MAX391 quad switches controlled by a serial interface. All digital inputs have 0.8V to 2.4V logic thresholds. It is used in serial data acquisition systems, avionics and ATE equipment.

.

Supply voltage range is 2.7V to 16V, ±2.7V to ±8V

.

Operating temperature range from 0°C to 70°C

.

SPI/QSPI, Microwire compatible serial interface

.

8 separately controlled SPST switches

.

Signal Paths with ±5V Supplies is 100 ohm

.

Rail to rail signal handling

.

Asynchronous RESET complementary input

.

Pin compatible with industry standard MAX335

.

ESD Protection per method 3015.7 is > 2KV

.

TTL/CMOS compatible inputs with +5V or ±5V supplies
