MAX4754ETE+

MAXIM INTEGRATED PRODUCTS  MAX4754ETE+  模拟开关, 数据和音频路由, DPDT, 2 放大器, 0.85 ohm, 1.8V 至 5.5V, TQFN, 16 引脚

The is a 0.5ohm, quad SPDT switch in 16 pin TQFN package. This low on-resistance analogue switch operates from a single +1.8V to +5.5V supply. Device is fully specified for nominal 3V applications. It has two logic control inputs with each input controlling two SPDT switches. Each switch has a 0.5ohm on-resistance in the NO and NC terminals making it ideal for switching audio signals. It is used at speaker headset switching, cellular phones, PDAs/handheld devices, audio/video signal routing and notebook computers.

.

Low RON 0.5ohm typ & 0.85ohm max audio switches

.

Operating temperature range from -40°C to 85°C

.

Channel to channel matching is 0.1ohm typ

.

On-resistance flatness is 0.2ohm typ

.

Total harmonic distortion is 0.035%

.

Rail to rail signal handling

.

Charge injection of 300pC

.

On-channel -3dB bandwidth is 10MHz at TA = +25°C

.

Crosstalk of -90dB at TA = +25°C

.

Off-isolation is -65dB at TA = +25°C
