MCP2200EV-VCP

MICROCHIP  MCP2200EV-VCP  演示电路板, MCP2200, USB至RS232, 测试点用于所有GPIO引脚, 9引脚D Sub连接器

MCP2200 USB 到 RS-232 演示板

是 USB 到 RS232 开发和评估板，用于 MCP2200 USB 到 UART 设备。 该板易于对 MCP2200 进行演示和评估。

通过 USB 供电

所有 GPIO 引脚的测试点

RS-232 9 引脚 D-sub 连接器

微型 USB 连接器

Tx 和 Rx LED 用于指示 USB 到 UART 流量（启用时）

用于配置设备特殊功能的软件

### 随附

信息表

欧时:
USB 2.0至串行，UART，转换器模块

得捷:
MOD EVAL USB/RS232 MCP2200

贸泽:
Interface Development Tools MCP2200 USB to RS232 Demo Board

艾睿:
USB To RS232 Development And Evaluation Board For The MCP2200 USB To UART Device

Allied Electronics:
Microchip MCP2200EV-VCP; USB to RS232 Demonstration Board For MCP2200

安富利:
USB To RS232 Development And Evaluation Board For The MCP2200 USB To UART Device

Chip1Stop:
USB To RS232 Development And Evaluation Board For The MCP2200 USB To UART Device

TME:
Dev.kit: Microchip

Verical:
USB To RS232 Development And Evaluation Board For The MCP2200 USB To UART Device

Newark:
The MCP2200EV-VCP is a USB to RS232 development and evaluation board for the MCP2200 USB to UART device. The board allows for easy demonstration and evaluation of the MCP2200. The accompanying PC software is used to evaluate/demonstrate the MCP2200 as a Virtual Com Port VCP device. The software also allows I/O control and custom device configuration.. The board is powered from USB and has a test point associated with each GPIO pin. In addition, two of these pins are connected to LEDs which can be used to indicate USB to UART traffic when the associated pins are configured as TxLED and RxLED pins respectively.
