MAX13046EELT+T

MAXIM INTEGRATED PRODUCTS  MAX13046EELT+T  芯片, 逻辑转换器

The is a single channel bidirectional low-level translator in 6 pin µDFN package. This device provides level shifting for data transfer in a multivoltage system. Externally applied voltages, VCC and VL, set the logic level on either side of the device. It utilizes a transmission gate based design to allow data translation in either direction VL and VCC on any single data line. MAX13046 is ideal for data transfer between low-voltage ASICs/PLDs and higher voltage systems.

.

Supply voltage range is 1.65V to 5.5V

.

Operating temperature range from -40°C to 85°C

.

Data rate of 8Mbps

.

Low supply current of 10µA

.

Ultra-low supply current in shutdown mode is 1µA max

.

Extended ESD protection on the I/O VCC lines to ±15KV human body model

.

Short-circuit protection
