MSMLJ20A
数据手册.pdf表面安装3000瓦的瞬态电压抑制器 SURFACE MOUNT 3000 Watt Transient Voltage Suppressor
• Suppresses transients up to 3000 watts @ 10/1000 µs
• Protection from switching transients and induced RF
• Protection from ESD, and EFT per IEC 61000-4-2 and IEC 61000-4-4
• Secondary lightning protection per IEC61000-4-5 with 42 Ohms source impedance:
-Class 1 & 2: MSML5.0A to MSML 170ACA
-Class 3: MSML5.0A to MSML150CA
-Class 4: MSML5.0A to MSML75CA
• Secondary lightning protection per IEC61000-4-5 with 12 Ohms source impedance:
\- Class 1: MSML5.0A to MSML170CA
\- Class 2: MSML5.0A to MSML90CA
\- Class 3: MSML5.0A to MSML48CA
\- Class 4: MSML5.0A to MSML24CA
• Secondary lightning protection per IEC61000-4-5 with 2 Ohms source impedance:
\- Class 2: MSML5.0A to MSML43CA
\- Class 3: MSML5.0A to MSML22CA
\- Class 4: MSML5.0A to MSML10CA
