MS3122E14-19P
数据手册.pdf
ITT Corporation
ITT电子
连接器与适配器
ITT CANNON MS3122E14-19P 圆形连接器, MIL-DTL-26482 I系列, 盒式安装插座, 19 触点, 压接引脚, 卡口, 14-19
The from ITT Cannon is MIL-DTL-26482 series I box mount receptacle with 19 contacts. MIL-DTL-26482 series I connectors are available in various shell styles and shell plating with 48hr, 500hr salt spray exposure. The unmated connectors and protective covers meet 48hrs exposure to MIL-STD-1344 method 1001 per MIL-DTL-26482. It has a well-proven electrical capability and is designed to withstand extreme shock, exposure and vibration.
- .
- Intermateable, intermountable, interchangeable for MIL-C-26482, VG95328 connectors
- .
- Self levelling 3 point bayonet coupling assures fast and reliable mating / unmating
- .
- Precise alignment utilizing five keyways
- .
- High contact density, environmentally sealed & suitable for harsh environments
- .
- Operating temperature range from -55°C to +125°C
- .
- Insulation resistance is 5000Mohm at 25°C
- .
- 500 mating cycles, operating voltage is 1000VAC
- .
- Resilient polychlorprene insulator & grommet
- .
- Aluminium alloy body material with olive drab chromate over cadmium plating
- .
- Copper alloy crimp pin contacts with gold plating
