FAIRCHILD SEMICONDUCTOR MOC3042M 光电耦合器, 三端双向可控硅输出, DIP, 6 引脚, 7.5 kV, 过零, 400 V
The MOC3042-M is a 400V Zero Crossing TRIAC Driver Output Optocoupler consists of a AlGaAs infrared emitting diode optically coupled to a monolithic silicon detector performing the function of a zero voltage crossing bilateral TRIAC driver. They are designed for use with a TRIAC in the interface of logic systems to equipment powered from 115VAC lines such as teletypewriters, CTRs, solid-state relays, printers and solenoids etc.
- .
- Simplifies logic control of 115VAC power
- .
- Zero voltage crossing
- .
- dv/dt of 2000V/µs Typical, 1000V/µs guaranteed
- .
- 400V Peak blocking voltage
