MAX383ESE+

MAXIM INTEGRATED PRODUCTS  MAX383ESE+  模拟开关, 精准, SPDT, 2 放大器, 35 ohm, 3V至15V, ± 3V至± 8V, NSOIC, 16 引脚

The is a precision, low voltage analogue switch in 16 pin NSOIC package. The single-pole single-throw switch is normally open poles, it offers low on-resistance less than 35ohm, to match to within 2ohm between channels and to remain flat over specified analogue signal range 4ohm max and also offer low leakage less than 250pA at +25°C and less than 2.5nA at +85°C and fast switching turn-on time less than 175ns and turn-off time less than 100ns. It is fabricated with Maxim"s low voltage silicon gate process for high system accuracy. Design improvements guarantee extremely low charge injection <5pC and low power consumption <10µW. It is used in sample and hold circuits, test equipment, heads-up displays, guidance and control systems, audio/video signal routing, military radios, communication systems, PBX, PABX and battery-operated systems.

.

Supply voltage range is 3V to 15V, ±3V to ±8V

.

Operating temperature range from -40°C to 85°C

.

Pin-compatible with DG403

.

Charge injection is < 5pC

.

Off-channel leakage is < 2.5nA at +85°C

.

TTL/CMOS-logic compatible with 3V, 5V, ±3V and ±5V supplies

.

Rail to rail analogue signal handling capability

.

Crosstalk is 90dB at TA = +25°C RL = 50 ohm, CL = 5pF, f = 1MHz
