MIC5207-3.3YM5

LDO/MIC5207-3.3YM5

General Description

The MIC5207 is an efficient linear voltage regulator with ultra-low-noise output, very low dropout voltage typically 17mV at light loads and 165mV at 150mA, and very low ground current 720µA at 100mA output. The MIC5207 offers better than 3% initial accuracy.

Designed especially for hand-held, battery-powered devices, the MIC5207 includes a CMOS or TTL compatible enable/shutdown control input. When in shutdown, power consumption drops nearly to zero.

Key MIC5207 features include a reference bypass pin to improve its already low-noise performance, reversed battery protection, current limiting, and overtemperature shutdown.

Features

• Ultra-low-noise output

• High output voltage accuracy

• Guaranteed 180mA output

• Low quiescent current

• Low dropout voltage

• Extremely tight load and line regulation

• Very low temperature coefficient

• Current and thermal limiting

• Reversed-battery protection

• “Zero” off-mode current

• Logic-controlled electronic enable

Applications

• Cellular telephones

• Laptop, notebook, and palmtop computers

• Battery-powered equipment

• PCMCIA VCC and VPP regulation/switching

• Consumer/personal electronics

• SMPS post-regulator/dc-to-dc modules

• High-efficiency linear power supplies
