LTC3569IFE#PBF
数据手册.pdfConv DC-DC Triple Step Down 2.5V to 5.5V 16Pin TSSOP EP
Adjust the voltage level of your devices with this synchronous step down DC to DC converter from . This converter"s 3 outputs can produce a current up to 1.2|0.6|0.6 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 5.5 V. With an adjustable output that has a voltage of 0.425 to 5.5 V, this is power management at its best. This device has a typical switch current of 2|1|1 A. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.5%Typ and line regulation of 0.2%/V. You can operate this at a switching frequency of 1000 to 3000|2250 kHz. This converter has an operating temperature range of -40 °C to 125 °C.
