LT1120IS8
数据手册.pdfIC REG LDO ADJ 125mA 8SOIC
Stable power is ideal for better processing this LDO linear regulator developed by will help do so. Its typical dropout voltage at current is 0.02@100uA|0.4@125mA V. This voltage regulation device"s single output can produce a current up to 0.125Min A. The best way to provide power to your application is by using this, which needs a voltage of at least 4.5 V and no higher than 36 V. With an adjustable output that has a voltage of 2.5 to 35.15 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.5% and line regulation of 0.015%/V. Its polarity is positive. The maximum dropout voltage is 0.05@100uA|0.65@125mA V. This voltage regulation device has an operating temperature range of -40 °C to 100 °C.
