LT1460GIZ-5#PBF

LINEAR TECHNOLOGY  LT1460GIZ-5#PBF  电压基准, 精准微功率, 系列 - 固定, LT1460系列, 5V, TO-226AA-3

The LT1460 series micropower band-gap Voltage Reference combines very high accuracy and low drift with low power dissipation. This series reference uses curvature compensation to obtain low temperature coefficient and trimmed precision thin-film resistors to achieve high output accuracy. The reference will supply up to 20mA with excellent line regulation characteristics, making it ideal for precision regulator applications. This series reference provides supply current and power dissipation advantages over shunt references that must idle the entire load current to operate. Additionally, the LT1460 does not require an output compensation capacitor, yet is stable with capacitive loads. This feature is important where PC board space is a premium or fast settling is demanded. In the event of a reverse battery connection, these references will not conduct current and are therefore protected from damage.

.

No output capacitor required

.

Reverse battery protection

.

Industrial temperature range

.

Temperature coefficient guaranteed to 125°C

.

0.075% Maximum trimmed to high accuracy

.

20mA Minimum output current

.

0.9V Minimum input/output differential
