LT3060EDC-15#TRMPBF

LINEAR TECHNOLOGY  LT3060EDC-15#TRMPBF  固定电压稳压器, LDO, 1.6V至45V, 300mV压差, 15V输出, 100mA输出, DFN-8

Stable power is ideal for better processing this LDO linear regulator developed by will help do so. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.075@1mA|0.15@10mA|0.24@50mA|0.3@100mA V. This voltage regulation device"s single output can produce a current up to 0.1 A. Using the part will provide the power your application needs by requiring a voltage only of 1.6 V and not exceeding a voltage of 45 V. With a fixed output that has a voltage of 15 V, this is power management at its best. By operating at a load regulation of 100mV and line regulation of 55mV you can provide a constant voltage at your output. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its polarity is positive. The maximum dropout voltage is 0.11@1mA|0.2@10mA|0.28@50mA|0.35@100mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
