LM3724IM5-3.08
TI
德州仪器
主动器件
TEXAS INSTRUMENTS LM3724IM5-3.08 复位电路, 低电平有效复位, 1V-5.5V输入, SOT-23-5
The is a Microprocessor Reset Circuit with active-low open-drain output. The microprocessor supervisory circuit monitors the power supplies in microprocessor and digital systems. It provides a reset to the microprocessor during power-up, power-down, brownout conditions and manual reset. The LM3724 asserts a reset signal whenever the supply decreases below the factory-programmed reset threshold. Reset will be asserted for at least 100ms even after VCC rises above the reset threshold.
- .
- Power supply transient immunity
- .
- Compatible with MAX811/812 applications
- .
- Guaranteed /RESET output valid for VCC >= 1V
- .
- 6µA Typical low supply current
- .
- Green product and no Sb/Br
