LT3009ESC8-1.2#TRMPBF
数据手册.pdfLDO Regulator Pos 1.2V 0.02A 8Pin SC-70 T/R
Keep calm and stay stable by implementing this LDO linear regulator developed by . Its typical dropout voltage at current is 0.115@100uA|0.17@1mA|0.25@10mA|0.28@20mA V. It has an overall accuracy of ±2 %. This voltage regulation device"s single output can produce a current up to 0.02 A. Using the part will provide the power your application needs by requiring a voltage only of 1.6 V and not exceeding a voltage of 20 V. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Users like the load regulation of 6mV and line regulation of 3mV. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its polarity is positive. The maximum dropout voltage is 0.18@100uA|0.25@1mA|0.31@10mA|0.35@20mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
