LM1117DT-ADJ
TEXAS INSTRUMENTS LM1117DT-ADJ 电压稳压器, LDO, 可调, 2.6V至15V输入, 1.2V压差, 1.25V至13.8V/0.8A输出, TO-252-3
The is a low dropout Linear Regulator with a dropout of 5V at 800mA of load current. It has the same pin-out as Texas Instruments" industry standard LM317. The LM1117 is available in an adjustable output voltage version. This Linear regulator offers current limiting and thermal shutdown. Its circuit includes a Zener trimmed band gap reference to assure output voltage accuracy to within ±1% and a minimum of 10µF tantalum capacitor is required at the output to improve the transient response and stability.
- .
- Current limiting and thermal protection
- .
- 0.2% Maximum line regulation
- .
- 0.4% Load regulation
- .
- 75uVrms Noise
- .
- Non-ceramic output capacitor
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
