LTC2052CS
数据手册.pdfIC OPAMP CHOPPER 3MHz RRO 14SO
DESCRIPTION
The LTC®2051/LTC2052 are dual/quad zero-drift operational amplifiers available in the MS8 and SO-8/GN16 and S14 packages. For space limited applications, the LTC2051 is available in a 3mm × 3mm × 0.8mm dual fine pitch leadless package DFN. They operate from a single 2.7V supply and support ±5V applications. The current consumption is 750μA per op amp.
FEATURES
■ Maximum Offset Voltage of 3μV
■ Maximum Offset Voltage Drift of 30nV/°C
■ Small Footprint, Low Profile MS8/GN16 Packages
■ Single Supply Operation: 2.7V to ±5.5V
■ Noise: 1.5μVP-P 0.01Hz to 10Hz Typ
■ Voltage Gain: 140dB Typ
■ PSRR: 130dB Typ
■ CMRR: 130dB Typ
■ Supply Current: 0.75mA Typ per Amplifier
■ Extended Common Mode Input Range
■ Output Swings Rail-to-Rail
■ Operating Temperature Range –40°C to 125°C
■ Available in 3mm × 3mm × 0.8mm DFN Package
APPLICATIONS
■ Thermocouple Amplifiers
■ Electronic Scales
■ Medical Instrumentation
■ Strain Gauge Amplifiers
■ High Resolution Data Acquisition
■ DC Accurate RC Active Filters
■ Low Side Current Sense
