LTC6268IS6#TRMPBF
数据手册.pdf
Linear Technology
凌力尔特
主动器件
LINEAR TECHNOLOGY LTC6268IS6#TRMPBF Operational Amplifier, Single, 1 Amplifier, 350MHz, 400V/µs, 3.1V to 5.25V, TSOT-23, 6Pins
The is a single 500MHz FET-input Operational Amplifier with extremely low input bias current and low input capacitance. It also features low input referred current noise and voltage noise making it an ideal choice for high speed transimpedance amplifiers, CCD output buffers and high-impedance sensor amplifiers. Its low distortion makes the LTC6268 an ideal amplifier for driving SAR ADCs. It operates on 3.1 to 5.25V supply and consumes 16.5mA per amplifier. A shutdown feature can be used to lower power consumption when the amplifier is not in use.
- .
- 5.5fA/√Hz 100kHz Current noise
- .
- 4.3nV/√Hz 1MHz Voltage noise
- .
- Extremely low CIN 450fF
- .
- Rail-to-rail output
- .
- 400V/µs Slew rate
