ADA4062-2BRZ-R7

微型，低功耗JFET输入运算放大器 Tiny, Low Power JFET-Input Op Amp

GENERAL DESCRIPTION

The ADA4062-2 and ADA4062-4 are dual and quad JFET-input amplifiers with industry-leading performance. They offer lower power, offset voltage, drift, and ultralow bias current. The ADA4062-2 B grade SOIC package features a typical low offset voltage of 0.5 mV, an offset drift of 5 μV/°C, and a bias current of 2 pA.

The ADA4062 family is ideal for various applications, including process controls, industrial and instrumentation equipment, active filtering, data conversion, buffering, and power control and monitoring. With a low supply current of 165 μA per amplifier, they are well suited for lower power applications.

FEATURES

  Low input bias current: 50 pA maximum

  Offset voltage

     1.5 mV maximum for B grade ADA4062-2 SOIC package

     2.5 mV maximum for A grade

  Offset voltage drift: 5 μV/°C typical

  Slew rate: 3.3 V/μs typical

  CMRR: 90 dB typical

  Low supply current: 165 μA typical

  High input impedance

  Unity-gain stable

  ±5 V to ±15 V dual-supply operation

  Packaging

     8-lead SOIC, 8-lead MSOP, 10-lead LFCSP, 14-lead TSSOP, and   16-lead LFCSP packages

APPLICATIONS

  Power controls and monitoring

  Active filters

  Industrial/process controls

  Body probe electronics

  Data acquisition

  Integrators

  Input buffering
