ADAS3022BCPZ

ANALOG DEVICES  ADAS3022BCPZ  芯片, 数据采集, 16位, 1MSPS, 40LFCSP

16 位数据采集系统，Analog Devices

### 数据采集系统 - Analog Devices

具有高通道密度的数据采集系统 DAS 适用于医疗成像、工业过程控制和自动测试设备。

得捷:
IC ADC 16BIT SAR 40LFCSP

立创商城:
ADAS3022BCPZ

欧时:
Analog Devices ADAS3022BCPZ 16 位 1Msps 数据采集系统集成电路, 40引脚 LFCSP封装

贸泽:
Analog to Digital Converters - ADC 1MSPS 16-Bit 8CH DAS

e络盟:
8通道数据采集系统, 16位, 1 MSPS, 4.75 V至5.25 V, LFCSP-40

艾睿:
8-Channel Single ADC SAR 1Msps 16-bit Serial 40-Pin LFCSP EP Tray

安富利:
The ADAS3022 is a complete 16-bit, 1 MSPS, successive approximation-based analog-to-digital data acquisition system, which is manufactured on Analog Devices, Inc., proprietary iCMOS® high voltage industrial process technology. The device integrates an 8-channel, low leakage multiplexer; a high impedance programmable gain instrumentation amplifier PGIA stage with high common-mode rejection; a precision, low drift 4.096 V reference and buffer; and a 16-bit charge redistribution analog-to-digital converter ADC with successive approximation register SAR architecture. The ADAS3022 can resolve eight single-ended inputs or four fully differential inputs up to ±24.576 V when using ±15 V supplies. In addition, the device can accept the commonly used bipolar differential, bipolar single-ended, pseudo bipolar, or pseudo unipolar input signals, as shown in Table 1, thus enabling the use of almost any direct sensor interface.The ADAS3022 simplifies design challenges by eliminating signal buffering, level shifting, amplification/attenuation, common-mode rejection, settling time, and any other analog signal conditioning challenge while allowing a smaller form factor, faster time to market, and lower cost.

Chip1Stop:
AFE General Purpose 1ADC 16bit 5V/±15V 40-Pin LFCSP EP Tray

Verical:
8-Channel Single ADC SAR 1Msps 16-bit Serial 40-Pin LFCSP EP Tray

Newark:
# ANALOG DEVICES  ADAS3022BCPZ  Special Function IC, Data Acquisition System, 4.75 V to 5.25 V, LFCSP-40

Win Source:
IC ADC 16BIT 1MSPS 1CH 40LFCSP
