ACJ5212P

超小型PC板类型 SUPER MINIATURE PC BOARD TYPE

FEATURES

• Smallest in its class, it is extremely compact at approx. 2/3 the size of previous products.

  Compared to our previous miniature type CT relay, both the 1 Form C and 10-pin and 8-pin twin types take up approx. two thirds the space and volume. This makes them ideal for relay unit miniaturization.

• Compact and high-capacity 25 A load switching

  High capacity control is possible while being compact and capable of motor lock load switching at 25 A, 14 V DC.

• Pin in Paste

.

compatible model added

  Models compatible with the recently increasing Pin in Paste technique reflow solder mounting have been added. Pin in Paste compatible models are the flux tight type.



.

The Pin in Paste method may sometimes be referred to as THRThrough-hole Reflow.

• Environmental protection specifications

  Cadmium-free contacts and use of lead free solder are standard. Environmental pollutants are not used.

TYPICAL APPLICATIONS

• Powered windows

• Automatic door locks

• Electrically powered mirrors

• Powered sunroofs

• Powered seats

• Lift gates

• Smart J/B related products, etc.
