AD711KN

精密，低成本，高速， BiFET运算放大器 Precision, Low Cost, High Speed, BiFET Op Amp

PRODUCT DESCRIPTION

The AD711 is a high speed, precision monolithic operational amplifier offering high performance at very modest prices. Its very low offset voltage and offset voltage drift are the results of advanced laser wafer trimming technology. These performance benefits allow the user to easily upgrade existing designs that use older precision BiFETs and, in many cases, bipolar op amps.

The superior ac and dc performance of this op amp makes it suitable for active filter applications. With a slew rate of 16 V/ms and a settling time of 1 ms to ±0.01%, the AD711 is ideal as a buffer for 12-bit D/A and A/D Converters and as a high-speed integrator. The settling time is unmatched by any similar IC amplifier.

FEATURES

Enhanced Replacement for LF411 and TL081

AC PERFORMANCE

   Settles to ±0.01% in 1.0 μs

   16 V/μs min Slew Rate AD711J

   3 MHz min Unity Gain Bandwidth AD711J

DC PERFORMANCE

   0.25 mV max Offset Voltage: AD711C

   3 μV/°C max Drift: AD711C

   200 V/mV min Open-Loop Gain AD711K

   4 μV p-p max Noise, 0.1 Hz to 10 Hz AD711C

   Available in Plastic Mini-DIP, Plastic SOIC, Hermetic

   Cerdip, and Hermetic Metal Can Packages

MIL-STD-883B Parts Available

   Available in Tape and Reel in Accordance with

   EIA-481A Standard

   Surface Mount SOIC

   Dual Version: AD712
