AD8038AKSZ-REEL7

ANALOG DEVICES  AD8038AKSZ-REEL7  运算放大器, 单路, 350 MHz, 1个放大器, 425 V/µs, 3V 至 12V, SC-70, 5 引脚

The is a single Voltage Feedback Amplifier for use with A/D drivers. The amplifier provides excellent overall performance. Additionally, it offers a high slew rate of 425V/µs and a low input offset voltage of 3mV maximum. The Analog Devices, Inc., proprietary XFCB process allows low noise operation 8nV/√Hz and 600fA/√Hz at extremely low quiescent currents. Given a wide supply voltage range 3 to 12V, wide bandwidth, the AD8038 amplifier is designed to work in a variety of applications where power and space are at a premium. The AD8038 amplifier has a wide input common-mode range of 1V from either rail and swing to within 1V of each rail on the output. This amplifier is optimized for driving capacitive loads up to 15pF.

.

High speed

.

Low noise

.

Low distortion

.

1mA/amplifier Supply low power
