AD7988-5BRMZ

ANALOG DEVICES  AD7988-5BRMZ  模数转换器, 16 bit, 500 kSPS, 单, 2.375 V, 2.625 V, MSOP

模拟至数字转换器 16 位，高达 195kSPS，Analog Devices

得捷:
IC ADC 16BIT SAR 10MSOP

立创商城:
AD7988-5BRMZ

欧时:
Analog Devices AD7988-5BRMZ 16 位 ADC, 差分输入, Serial SPI/QSPI/Microwire接口, 10引脚 MSOP封装

e络盟:
模数转换器, 16 bit, 500 kSPS, 伪差分, SPI, 单, 2.375 V

艾睿:
Single Channel Single ADC SAR 500ksps 16-bit Serial 10-Pin MSOP Tube

安富利:
The AD7988-5 is a 16-bit, successive approximation, analog-to-digital converters ADC that operate from a single power supply, VDD. The AD7988-1 offers a 100 kSPS throughput, and the AD7988-5 offers a 500 kSPS throughput. They are low power, 16-bit sampling ADCs with a versatile serial interface port. On the CNV rising edge, they sample an analog input, IN+, between 0 V to VREF with respect to a ground sense, IN-. The reference voltage, REF, is applied externally and can be set independent of the supply voltage, VDD.The SPI-compatible serial interface also features the ability to daisy-chain several ADCs on a single 3-wire bus using the SDI input. It is compatible with 1.8 V, 2.5 V, 3 V, or 5 V logic using the separate supply, VIO.The AD7988-5 generics are housed in a 10-lead MSOP or a 10-lead LFCSP with operation specified from -40°C to +125°C.

Chip1Stop:
Single ADC SAR 500ksps 16-bit Serial 10-Pin MSOP Tube

Verical:
Single Channel Single ADC SAR 500ksps 16-bit Serial 10-Pin MSOP Tube

Newark:
# ANALOG DEVICES  AD7988-5BRMZ  Analog to Digital Converter, 16 bit, 500 kSPS, Single, 2.375 V, 2.625 V, MSOP

DeviceMart:
ADC 16BIT 500KSPS 1.25LSB 10MSOP
