10位， 60 MSPS A / D转换器 10-Bit, 60 MSPS A/D Converter
GENERAL DESCRIPTION
The AD9051 is a complete 10-bit monolithic sampling analog to-digital converter ADC with an onboard track-and-hold and reference. The unit is designed for low cost, high performance applications and requires only 5 V and an encode clock to achieve 60 MSPS sample rates with 10-bit resolution.
FEATURES
60 MSPS Sampling Rate
9.3 Effective Number of Bits at fIN= 10.3 MHz
250 mW Total Power at 60 MSPS
Selectable Input Bandwidth of 50 MHz or 130 MHz
On-Chip T/H and Voltage Reference
Single 5 V Supply Voltage
5 V or 3 V Logic I/O Compatible
Input Range and Output Coding Options Available
APPLICATIONS
Medical Imaging
Digital Communications
Professional Video
Instrumentation
Set-Top Box
