ADUM3223BRZ
数据手册.pdfANALOG DEVICES ADUM3223BRZ 数字隔离器, 2通道, 38 ns, 3 V, 5.5 V, SOIC, 16 引脚
ADuM3223，3kV 有效值隔离精密半桥驱动器，Analog Devices
ADuM3223 为 4A 隔离半桥栅极驱动器，其采用 Analog Devices 的 iCoupler® 技术，可提供独立且隔离的高侧和低侧输出。 它们结合了高速 CMOS 和单片电路变压器技术，可提供出色的性能特征，优于目前的同类产品，例如脉冲变压器与栅极驱动器 IC 组合。
隔离额定值：3000 V 有效值
### 绝缘电源驱动器
绝缘驱动器系列，适用于采用 IGBT 或 MOSFET 功率输出设备的应用
得捷:
DGTL ISO 3KV 2CH GATE DVR 16SOIC
立创商城:
ADUM3223BRZ
欧时:
Analog Devices ADUM3223BRZ 双 半桥 MOSFET 功率驱动器, 4A, 3.3 → 5 V电源, 16引脚 SOIC封装
艾睿:
Driver 4A 2-OUT High and Low Side/Isolated Gate Driver Half Brdg 16-Pin SOIC N Tube
安富利:
Isolated Precision Half Bridge Driver 16-Pin SOIC N
Chip1Stop:
Digital Isolator CMOS 2-CH 16-Pin SOIC N Tube
Verical:
Driver 4A 2-OUT High and Low Side/Isolated Gate Driver Half Brdg 16-Pin SOIC N Tube
Newark:
The ADUM3223BRZ is an Isolated Precision Half-bridge Driver that employs iCoupler® technology to provide independent and isolated high-side and low-side outputs. Combining high speed CMOS and monolithic transformer technology, this isolation component provides outstanding performance characteristics superior to the alternatives, such as the combination of pulse transformers and gate drivers. The isolator provides two independent isolated channels. In comparison to gate drivers employing high voltage level translation methodologies, it offers the benefit of true, galvanic isolation between the input and each output. Each output may be continuously operated up to 537V peak relative to the input, thereby supporting low-side switching to negative voltages. The ADUM3223 provides reliable control over the switching characteristics of IGBT/MOSFET configurations over a wide range of positive or negative switching voltages.
Win Source:
DGTL ISO 3KV 2CH GATE DVR 16SOIC
